Brightness Testing Portable Colorimeter Below 0.08 Repeatability Compact Design

Place of Origin China
Brand Name CHN spec
Certification CE
Model Number CS-260
Minimum Order Quantity 1
Price negotiable
Packaging Details Inner Box: Foam Package Outer Box: Carton box Size: 25x21x20cm
Delivery Time 5-7 days
Payment Terms T/T, Western Union, MoneyGram,Paypal
Supply Ability 1000 per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Illumination System D/8,SCI Measuring Caliber 11mm (optional 15mm,4mm,6mm)
Storage 1000 Test Results Instrument Size 77x86x210mm
Measurement Time 2 Second Measuring Range 0-200%
Repeatability Below 0.08 Measuring Light Source LED
Languages English And Chinese Device Weight 550g (without Battery)
High Light

colorimeter device

,

digital color meter

Leave a Message
Product Description

Handy Color Testing Brightness Tester Food Colorimeter For Plastic





Introduction:



Handy brightness tester colorimeter is widely used in different industries for color difference test such as paper, electroplating oxide, paint, plastic cement, printing, weaving and dyeing.It measures the sample color data L*a*b*, L*c*h*, color difference ΔE and ΔLab according to CIE color space.Our colorimter could work with micro printer to print the testing result anywhere and anytime.





Specifications:



Type CS-260
Color Swatches Pantone
Illumination system 8/d(8°/diffused illumination)
SCI
Testing Port Diameter About 8mm
Measuring conditions CIE 10° standard observer; CIE D65 light source
Measuring range L*:1-100
Repeatability Standard deviation within delta E*ab*, below 0.08(testing condition: measure the white calibration board 80 times for average)
Storage 100 sets of standard samples; up to 100 under each standard sample
Measuring time About 0.5 seconds
Measuring light source LED
languages Chinese, English
Power Four AA1.5V Alkaline battery or nickel-metal hydride batterys; Exclusive DC5V adapter
port USB2.0 printer
weight 550g
Size 77×86×210mm





Competitive Advantage:



1). Device sensor exports Japan and information processing chip is from USA, which guarantee the optical signal transfer accuracy and electrical signal stability.

2). Multiple color space display color values : L*a*b,L*c*h,Yxy.

3). The device could store 100 standard sample groups and every sample group could store 100 sample data.

4). Ergonomic Design

5). Free Color Management Software

6). Establish the Prototype Data L*a*b* by manually

7). Test different points on sample and get the average value. It is widely used for color control whose color is not uniform.





Free Colorimeter QC Software:

Our device is with mature PC management software. It could connect the colorimeter with the PC. With the software, we could save and manage the color data, derive the data, generate testing report, test report printing. It will help the color analysis worker finish the job much easier.

Brightness Testing Portable Colorimeter Below 0.08 Repeatability Compact Design 0





Packing List:



Packing Material:Canvas bag with carton box

Packing Size:230x230x240mm

Packing Weight:2.4kgs

Delivery time:3-20 days after payment received.

Qty. Name Qty. Name
1 Main Instrument 1 Power Line
1 Operating Manual 1 USB Cable
1 Driving Software 1 Black/White Calibration Tiles
1 Color QC Software 1 Packing List

Brightness Testing Portable Colorimeter Below 0.08 Repeatability Compact Design 1



Company Information:



Our CHNSpec Technology., Ltd are specialized on manufacturing spectrophotometers, colorimeters and gloss meters. Our products have gotten 10 Invention Patents including 1 American Invention Patent, 8 Utility Model Patents, 4 Appearance Patents and 3 Software Copyrights till now. I believe our quality products will be your better choice.You are warmly welcome to visit and purchase from us.
