    Product Details:

    Place of Origin: China
    Brand Name: CHNspec
    Certification: CE
    Model Number: CS-288

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: Negotiable
    Packaging Details: Inner Box: Foam Package Outer Box: Carton box Size: 25x21x20cm
    Delivery Time: 3-5 working days
    Payment Terms: T/T, Western Union, MoneyGram,Paypal
    Supply Ability: 200 sets per month
    Contact Now
    Detailed Product Description
    Illumination System: D/8,SCI Measuring Caliber: 11mm (optional 15mm,4mm,6mm)
    Storage: 1000 Test Results Instrument Size: 77x86x210mm
    Measurement Time: 2 Second Measuring Range: 0-200%
    Repeatability: Below 0.08 Measuring Light Source: LED
    Languages: English And Chinese Device Weight: 550g (without Battery)
    Interface: USB 2.0 Memory: 20000 Samples

    Portable Dying Colour Measurement Spectrophotometer with 0.08 Repeatability




    Colour Measurement Spectrophotometer Introduction

    Colour measurement spectrophotometer is also called spectro meter or color meter. It is widely used in different industries such as plastic, cement, printing, paint, weaving and dyeing.It measures the sample color data L*a*b*, L*c*h*, color difference ΔE and ΔLab according to CIE color space.It is also suitable for Ganz whiteness, CIE/ISO whiteness,ASTM whiteness,Hunter whiteness and other whiteness measurement.


    Portable Dying Colour Measurement Spectrophotometer with 0.08 Repeatability



    Colour Measurement Spectrophotometer Specifications



    Type CS-288
    Illumination

    di/8(Diffused Illumination, 8 degree viewing)
    (conform to CIE No.15,ISO 7724/1,ASTM E1164,DIN 5033 Teil7, JIS Z8722

    Condition c standard)

    Size of integrating sphere Φ40mm, Avian diffused reflection surface coating
    Light source CLED
    Wavelength 400-700nm
    Spectrum Resolution 10nm
    Measurement Time 2s
    Repeatability

    Standard Deviation ΔE*ab 0.08(when a white calibration plate is measured 30 x at

    10-second intervals after calibration)

    Observe Angles 2° and 10°
    Light Source

    A,C,D50,D55,D65,D75,F1,F2,F3,F4,F5,F6,F7,F8,F9,F10,F11,F12,DLF,TL83,TL84,

    NBF,U30,CWF,U35

    Display

    Chromaticity value(L*a*b,L*C*h), delta E value, pass/fail, color tendency, average,

    generate test report, spectrum reflectance figure /data

    With camera to see the measurement area, spectrum reflectance figure /data,

    manual input target data

    Color Difference Formula ΔE*ab,ΔE*CH,ΔE*uv,ΔE*cmc(2:1),ΔE*cmc(1:1),ΔE*94,ΔE*00
    Color Space CIE-L*a*b,L*C*h,L*u*v,XYZ,Yxy,Reflectance
    Other WI(ASTM E313-10,ASTM E313-73,CIE/ISO,AATCC,Hunter,Taube Berger,Ganz,Stensby) YI(ASTM D1925,ASTM E313-00,ASTM E313-73)
    metameric index ,staining fastness , Color fastness
    Light Source Lifetime 5 years, 1.5 million times
    Language Chinese and English
    Operating Temperature 5~45℃, relative humidity 80% or below( at 35°C ),no condensation
    Power Rechargeable Lithium Battery 8.4V/2000mAh, adaptor DC12V




    Colour Measurement Spectrophotometer Advantage

    1). Automatic gloss compensation technology
    2). Every test calibration technology
    3). Patented Technology for stability
    4). For YI, WI and Tint measurement
    5). Obtain National Metrology Certification
    6). SCS optional engine
    7). Highest precision colorimeter
    8). Adopt spectral measurement theory for high accuracy
    9). Adopt CLEDs light source---spectrally balanced LED light source
    10). Optional accessories for different functions


    Portable Dying Colour Measurement Spectrophotometer with 0.08 Repeatability



    Colour Measurement Spectrophotometer Free Color QC Software

    Device is with mature color QC software which can connect the colorimeter with PC. With the software, we could save and manage the color data, derive the data, generate testing report,print test report.It will help the color analysis worker finish the job much easier.





    Colour Measurement Spectrophotometer Packing List



    Portable Dying Colour Measurement Spectrophotometer with 0.08 Repeatability



    Qty. Name Qty. Name
    1 Main Instrument 1 Power Line
    1 Operating Manual 1 USB Cable
    1 Driving Software 1 Black/White Calibration Tiles
    1 Color QC Software 1 Packing List
