China Portable Color Spectrophotometer manufacturer

Scientific Instruments Laboratory Colorimeter Device For Measuring Color

Product Details:
Place of Origin: China
Brand Name: CHNspec
Certification: CE
Model Number: CS-200
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Inner Box: Foam Package Outer Box: Carton box Size: 25x21x20cm
Delivery Time: 3-5 working days
Payment Terms: T/T, Western Union, MoneyGram,Paypal
Supply Ability: 200 sets per month
Contact Now

Detail Information

Illumination System: D/8,SCI Measuring Caliber: 8mm
Storage: 1000 Test Results Instrument Size: 77x86x210mm
Measurement Time: 2 Second Measuring Range: 0-200%
Repeatability: Below 0.08 Measuring Light Source: LED
Languages: English And Chinese Device Weight: 550g (without Battery)

Product Description

Measurement for Color , Scientific Instruments Lab Colorimeter for Measuring Color





Introduction:



CS-200 colorimeter is specially designed for color measurement of opaque materials. It could test the color difference for meat,coffee, tomato sauce, colorant,pigment and other materials. It measures the sample color space L*a*b*, L*c*h*, color difference ΔE and ΔLab according to CIE color space.





Competitive Advantage



1). Free Color Management Software

2). Ergonomic Design

3). Can Test Degree of Whiteness and Yellow Degree

4). Multiple color space display color values : L*a*b,L*c*h,Yxy

5). Device sensor exports Japan and information processing chip is from USA, which guarantee the optical signal transfer accuracy and electrical signal stability

6). Establish the Prototype Data L*a*b* by manually

7). The device could store 100 standard sample groups and every sample group could store 100 sample data.





Specifications



Type CS-200
Illumination system 8/d(8°/diffused illumination)
SCI
Testing Aperture Diameter 8mm (option 4mm)
Measuring conditions CIE 10° standard observer; CIE D65 light source

Display



Chromaticity Value:L*a*b*,L*c*h,ΔE*ab,relative RGB value

YI (yellowness index) and WI (whiteness index)

Measuring range L*:1-100
Repeatability Standard deviation within delta E*ab*,below 0.08(testing condition: measure the white calibration board for average)
Storage 100 sets of target; 100 pcs samples under each target
Measuring time About 0.5 seconds
Measuring light source LED
languages Chinese, English
Power Four AA1.5V Alkaline battery or nickel-metal hydride batterys; Exclusive DC5V adapter
port USB2.0 printer
weight 550g
Size 77×86×210mm





Free Colorimeter QC Software

Our colorimeter comes with mature PC software. It could connect the colorimeter with the PC. With the software, we could save and manage the color data, derive the data, generate testing report, test report printing. It will help the color analysis worker finish the job much easier.

Scientific Instruments Laboratory Colorimeter Device For Measuring Color





Packing List



Packing Material:Canvas bag with carton box

Packing Size:230x230x240mm

Packing Weight:2.4kgs

Delivery time:3-20 days after payment received



Qty. Name Qty. Name
1 Main Instrument 1 Power Line
1 Operating Manual 1 USB Cable
1 Driving Software 1 Black/White Calibration Tiles
1 Color QC Software 1 Packing List



Scientific Instruments Laboratory Colorimeter Device For Measuring Color
